Keysight Technologies (Agilent HP) N9030B-526

Send Request
  • $92097

Send to a Friend
Flag of USAEquipment Location: USA
View Description>
Hide Description

Description of Keysight Technologies (Agilent HP) N9030B-526

Categories: Analyzers Signal, Miscellaneous Signal Analyzers

Manufacturer: Keysight Technologies (Agilent HP)

Model: N9030B

Condition: Used

Keysight N9030B-526

2 Hz to 26.5 GHz

526Frequency Range, 2 Hz to 26.5 GHz Installed
B2XAnalysis bandwidth, 255 MHz Installed
BBAI/Q baseband inputs, analog Installed
EP0Enhanced phase noise, DDS LO Installed
EXMExternal mixing Installed
LNPLOW NOISE PATHInstalled
MPBMicrowave preselector bypass Installed
RTSReal time data streaming Installed

1DVR001AROM/CD-R/RW drive On request
1KBD001AUSB keyboard-smaller keyboard On request
1MSE001AMouse On request
MLP001AMinimum loss pad, 50 to 75 ohm On request
1CN103AHandle kit 177.0mm H (4U) - two front handles - New Phantom Gray Color On request
1CP105ARack mount flange and handle kit 177.0mm H (4U) - two brackets and front handles - Phantom Gray Color On request
107Audio input and digitizer On request
12MOn request
1CR014ARack Slide Kit for 17-inch and 20-inch Mounting Holes On request
CV1117ACover, Front Panel, Phantom Gray for 4U X-Series Signal Analyzers On request
24MOn request
36MOn request
60MOn request
A6JANSI Z540-1-1994 Calibration On request
ALVAuxiliary log video output On request
N90EMQAMBWLAN 4096QAM modulation On request
B1XAnalysis Bandwidth, 160 MHz On request
B2XAnalysis bandwidth, 255 MHz On request
B40Analysis bandwidth, 40 MHz On request
B5XAnalysis bandwidth, 510 MHz On request
B85Analysis bandwidth, 85 MHz On request
BBAI/Q baseband inputs, analog On request
N90EMRBEBResolution Bandwidth Extended On request
C12On request
C35RF input Connector, 3.5 mm, male On request
C36On request
C60On request
CR3Connector rear, second IF output On request
CRPConnector rear, programmable IF output On request
N90E1EDPBOn request
N90EMEDPBEnhance Display Package On request
N90EMTDSBTime Domain Scan On request
EA3Electronic attenuator, 3.6 GHz On request
EP0Enhanced phase noise, DDS LO On request
EXMExternal mixing On request
FBPOn request
FS2On request
LNPLOW NOISE PATHOn request
M01On request
M02On request
M03On request
E9068EM0EOn request
N9080EM0ELTE and LTE-Advanced FDD Measurement Application On request
N9054EM0EVector Modulation Analysis Digital Demodulation Measurement Application On request
N9081EM0EBluetooth (TM) Measurement Application On request
N9082EM0ELTE and LTE-Advanced TDD Measurement Application On request
N9083EM0EOn request
N9084EM0EShort Range Communications and IoT Measurement Application On request
N9085EM0E5G NR Measurement Application On request
N9091EM0EMeasuring Receiver Application On request
N9092EM0EAvionics Measurement Application On request
N9061EM0ERemote Language Compatibility Measurement Application On request
N9062EM0ESCPI Language Compatibility Measurement Application On request
N9063EM0EAnalog Demodulation Measurement Application On request
N9067EM0EPulse Analysis Measurement Application On request
N9068EM0EPhase Noise Measurement Application On request
N9069EM0ENoise Figure Measurement Application On request
N9071EM0EGSM/EDGE/Evo Measurement Application On request
N9073EM0EW-CDMA/HSPA+ Measurement Application On request
N9077EM0EWLAN 802.11a/b/g/j/p/n/af/ah Measurement Application On request
N6141EM0EEMI Measurement Application On request
N9054EM1EVector Modulation Analysis Custom OFDM Application On request
N9077EM3EWLAN 802.11ac/ax Measurement Application, limited On request
N9080EM3ENB-IoT and eMTC FDD Measurement Application On request
N9080EM4ELTE V2X measurement application On request
N9077EM4EWLAN 802.11be Measurement Application, limited On request
N90EMEMCBBasic EMC Functionality On request
MPBMicrowave preselector bypass On request
P03Preamplifier, 3.6 GHz On request
P08Preamplifier, 8.4 GHz On request
P13Preamplifier, 13.6 GHz On request
P26Preamplifier, 26.5 GHz On request
N90EMFP2BFast power On request
P44Preamplifier, 44 GHz On request
P50Preamplifier, 50 GHz On request
RTRReal-time spectrum recorder and analyzer application example On request
RTSReal time data streaming On request
N90EMESCBExternal Source Control On request
SF1Security features, exclude launching programs On request
SF2Security features, prohibit saving results On request
SF3Security feature, secure RAM disk boot On request
N90EMPSMBPower Suite Measurement Application On request
N90EMFT1BFrequency Mask Trigger, Basic Detection On request
N9030RT1BReal-time analysis up to maximum available BW, Basic Detection On request
N9030RT2BReal-time analysis up to maximum available BW, Optimum Detection On request
N90EMFT2BFrequency Mask Trigger, Optimum Detection On request
N90EMDUABDuplex IF RTSA On request
NULLOn request
W10On request
YAVScreen video, log video and linear video On request

Addable options follow the same discount percentage as the listed offer.

Request a customized version of this model by requesting a Custom Quote

Benchmark Performance in Signal Analysis

PXA signal analyzers are ideally suited for high-performance research and development (R&D) applications in aerospace/defense and commercial wireless communications. The PXA analyzes signals over wider bandwidths, reduces measurement uncertainty, and reveals previously hidden signals with noise floor extension (NFE). Unravel complex signals through the PXA’s broad set of measurement applications and demodulation capabilities.

  • Analyze more with a wide frequency with up to 510 MHz analysis bandwidth
  • See small signals in the presence of large ones with up to 75 dB of spurious-free dynamic range (SFDR)
  • Extend the frequency up to 110 GHz with Keysight smart mixers
  • Record, analyze, and simulate real-world scenarios with gap-free streaming up to 255 MHz
  • Capture transient or intermittent signals with optional real-time spectrum analysis capabilities
  • Meet stringent data security requirements with a removable solid-state drive and other optional features

Specifications

  • DANL @1 GHz: -174 dBm
  • Maximum Analysis Bandwidth: 510 MHz
  • Maximum Real-Time Bandwidth: 510 MHz
  • Phase Noise @1 GHz (10 kHz offset): -136 dBc/Hz
  • Type: Benchtop
  • Keysight N9030B-526 Data sheet
  • Keysight N9030B-526 Configuration Guide
  • Keysight N9030B-526 User Manual
