National Instruments cDAQ-9132 CompactDAQ Controller

The cDAQ-9132 is a high-speed CompactDAQ Controller developed by National Instruments. The cDAQ-9132 has multiple part numbers: 783338-01, 783339-01, and 156210E-02L. The first version comes with Windows OS and the second version has Linux RT as the controller OS. The cDAQ-9132 is a four-slot Controller. This model is compatible with C Series devices and is used for data transfer, synchronization, and timing control. This Controller features many standard expansion and connectivity functions, such as SD storage and several interface connections like USB, RS232 serial, Ethernet, and trigger terminals. The cDAQ-9132 can be connected to four C Series I/O modules simultaneously. This model also supports the CAN measurement and logging system.

The cDAQ-9132 CompactDAQ Controller incorporates an Intel Atom E3825 dual-core processor. The CPU frequency of this model is 1.33 GHz. The onboard processor features 1 MB cache. The NI cDAQ-9132 also has 2 Ethernet ports for the network interface. The cDAQ-9132 offers 3 communication speeds. The supported communication speeds are 10 Mb/s, 100, Mb/s, and 1000 Mb/s. This model features one RS-232 port for serial communication. The maximum baud rate is 115.2 kbps. The serial port can sustain overvoltage up to +24V. The cDAQ-9132 offers 3 ports for the USB interface. These ports can interface with USB 2.0. This model can transfer data at a maximum rate of 480 Mb/s through USB ports. The USB host ports can bear a maximum current of 1 A.

The cDAQ-9132 CompactDAQ Controller is a reliable and rugged controller. The cDAQ-9132 is certified according to industry standards. The cDAQ-9132 also features a small display port, which supports the display resolution of 2560 x 1600 at 60 Hz. The battery of the controller can last up to 10 years.
