Item#: 28359
Description
The 930 Compact IC Flex is Metrohm’s new ion chromatograph for routine analysis developed with a focus on the requirements of contract laboratories and QC laboratories in all kinds of industries. Rugged design, perfect ease of use and outstanding system reliability are key features of the 930 Compact IC Flex. Monitoring and control functions for system parameters, service intervals, calibrations, and results take the stress out of daily routine operation while ensuring high-quality measuring results even when things get hectic in the laboratory.
The new 930 Compact IC Flex system as its name says offers the highest possible degree of flexibility: You can choose from a complete range of separation columns, suppressors and detectors to configure a customized solution that meets your specific analytical requirements. If necessary, the 930 Compact IC Flex can also be fitted with a column oven as well as an eluent and sample degasser. It goes without saying that the unique Metrohm Inline Sample Preparation («MISP») techniques are available in the new system, as are numerous options for automation.
Combustion IC is used for analysis per method EPA 1621, as well as ASTM D7994, ASTM D7359, ASTM D8150, ASTM D8247, UOP991 and others.
Highlights:
Compact system for routine analysis of anions, cations and polar substances in the range of µg/L to g/L
Intelligent ion chromatography for superior reliability
Modular kit of system components and accessories for custom system configuration
Can be combined with all types of detection: conductivity, UV/VIS, amperometry
Space-saving design, easily accessible system components
STREAM – the green way of suppression
Complete automation and unique Metrohm Inline Sample Preparation («MISP») possible
Complies with all GLP and FDA requirements
Multi-language MagIC Net software for simple and intuitive operation
Comprehensive monitoring- and control functions for high quality results
Specifications:
General:
Compact IC system with modular design
Intelligent system components
Combination with various detectors possible
Metal-free flow path with operation pressure range of 0–35 MPa
Intelligent system components: Intelligent technology is integrated in the following system components, among others; iPump, etector, iColumn, 800 Dosino
Eluent and sample degasser: Organic modifier, 0–100% (no PFC [perfluorocarbons]), Material, fluoropolymer
High-pressure pump: Serial dual-piston pump with two valves and flow range-optimized, intelligent pump heads, flow rate 0.001–20 mL/min
Injection valve:
Injection volume
Internal loop: 0.25, 1 µL
Sample loops: 1.5, 5, 10, 20, 50, 100, 250, 1’000 µL
Column oven:
Temperature range: 0…+80 °C (ambient temperature +5…+40 °C)
Stability: <0.05 °CSuppressors : «MSM», «MSM-HC» and «MSM-LC»: Metrohm Suppressor Modules for chemical suppression applicable for anion and organic acid analysisType: «Micro Packed Bed» suppressorRegeneration: STREAM with peristaltic pump or 8Organic modifier: 0–100%, «MCS» Metrohm CO2 Suppressor:Type: CO2 removal with fluoropolymer technologyOrganic modifier: 0–100% (no PFC [perfluorocarbons])Detectors: Options for integration in the system include:Conductivity detectionUV/VIS detectionAmperometric detectionConductivity detector: Intelligent high-performance conductivity detector with DSP – «Digital Signal Processing»Measuring range: 0–15'000 µS/cm – without range switchingTemperature: 20–50 °C in 5 °C incrementsTemperature constancy: <0.001 °CCell volume: 0.8 µLElectronic noise: <0.1 nS/cm (at 1 µS/cm)Baseline noise: <0.2 nS/cm (e.g. A Supp 5, standard conditions)Peristaltic pumps:Rotational speed: 0–42 rpm in increments of 6 rpmShift direction: Clockwise and counterclockwiseGradients:Dose-in Gradient: binary, ternary, quaternary, quinaryProgression: step, linearControl: MagIC Net Compact, Professional and Multi ion chromatography softwareAutomation:Combinable autosamplers: 858 Professional Sample Processor,919 IC Autosampler plus, 863 Compact IC Autosampler, 889 IC Sample Center,814 USB Sample Processor, 815 Robotic USB Sample Processor XLMetrohm Inline Sample Preparation «MISP»: Options for integration in the system include;Inline UltrafiltrationInline DialysisInline Matrix EliminationInline DilutionInline ExtractionMetrohm injection techniques: Every 930 Compact IC Flex is pre-installed with full-loop injection; options for integration in the system include:Internal-loop injectionMetrohm intelligent Partial-Loop Injection Technique «MiPT»Metrohm intelligent Pick-up Injection Technique «MiPuT»
