Tektronix P7313 Z-Active Differential Probe
Tektronix has created a revolutionary Z-Active probe architecture that sets the industry benchmark for signal fidelity. Tektronix active probe architecture preserves high bandwidth while providing improved connectivity with low loading. The Z-Active architecture is a hybrid approach composed of a distributed attenuator topology feeding an active probe amplifier.
The Z-Active probes use a tiny passive probe tip element that is separate from the amplifier, extending the usable reach of the probe. In traditional active probes, adding this much length can introduce signal fidelity problems. However this architecture maintains high DC input resistance and presents a higher AC impedance than previous probe architectures. It accomplishes this while providing significant length between the probe body and the probe attachment point to the DUT. This architecture provides the best of both worlds: high DC impedance like existing active probes and the stable high frequency loading of Z0 probes.
Signal Fidelity
You can be confident in the signal fidelity of your measurements because the Z-Active architecture provides:
- High bandwidth
- Excellent step response
- Low loading
- High CMRR
Extended Linear Dynamic Range
Many of today’s logic signals and serial bus signals require the capability to measure up to several volts peak to peak. These voltage levels may
